Overview
The Laguna 19-38 Drum Sander is an open-ended drum sander that sands 19 inches wide in a single pass and up to 38 inches in two passes. INTELLISAND Technology automatically adjusts conveyor speed to prevent gouging or damaging stock, and a patented, tool-free abrasive attachment system keeps the abrasive tensioned and aligned, with an open stand and storage shelf included.
Key Features
- 38″ wide sanding in two passes, 19″ in a single pass
- INTELLISAND Technology automatically adjusts conveyor speed
- Patented, tool-free abrasive attachment system maintains tension and prevents overlap
- Fast Adjust Lever for quick, accurate alignment when sanding wider than the drum
- Self-cooling drum prevents overheating and extends abrasive life
- Adjustable tension rollers prevent snipe
- Cast iron and steel construction for strength and reduced vibration
- Flatness guaranteed to within .010″ across the conveyor
- Open stand with storage shelf included; casters optional
- CSA certified
Specifications
| Max. Sanding Width | 38″ (two passes), 19″ (single pass) |
|---|---|
| Min. Length | 2-1/4″ |
| Max. Thickness | 4″ |
| Min. Thickness | 1/32″ |
| Dimensions | 27D x 46W x 52H (on stand) |
| Drum | 5″ x 19″ extruded aluminum |
| Drum Speed | 1740 RPM |
| Dust Hood | 1 x 4″ vacuum port, min. 600 CFM recommended |
| Conveyor Motor | 43 in-lb torque, direct drive DC motor, 0–10 FPM variable |
| Drive Motor (TEFC) | 1-3/4 HP |
| Power Requirements | 110V, 15 amp |
| Shipping Weight | 286 lbs (3 boxes incl. stand) |
