Plunge Cut Track Saw TS 75 EQ-F-Plus-FS

Original price $975.00 - Original price $975.00
Original price
$975.00
$975.00 - $975.00
Current price $975.00

Items included and different models


  • This tool

    Plunge Cut Track Saw TS 75 EQ-F-Plus-FS
    $
    975.00
    Package contents

    75" Guide Rail FS 1900

    hex key 5 mm

    HW standard saw blade W36

    plug it-power cable (4 m)

    sight window

    splinterguard

    Systainer SYS3 M 437



  • Comparable product

    Package contents

    75" Guide Rail FS 1900

    hex key 5 mm

    HW standard saw blade W36

    plug it-power cable (4 m)

    sight window

    splinterguard

    Systainer SYS3 M 437



  • Functions

    Power and precision in the palm of your hand

    Experience the incredible power of the TS 75 plunge cut saw. No other saw comes close to its power and pinpoint accuracy. Capable of cutting material that is 2-3/4" thick, this saw will leave an edge that is both burn and splinter-free, creating edges that are clean enough to glue without any further prep work. The TS 75 is suitable for cutting solid doors, truing rough lumber, cutting out window frames, and a host of other applications. Save time and create matched panels by cutting stacked sheet goods with one cut. Try the TS 75 once, and you will never look back.

    • When used with Festool guide rails, you can achieve perfectly straight and splinter-free cuts.
    • Spring-loaded riving knife (splitter) keeps the cut kerf open so that the material does not pinch the blade. This reduces the chance of kickback.
    • The slip clutch helps to minimize the risk of a kickback and minimizes wear on the blade, gear case, and motor.
    • Blade changes are easier and safer using the FastFix system which locks switch and arbor simultaneously for easy arbor bolt removal.

    Product details

    TS 75 EQ-F-Plus-FS
    • Power

      The TS 75 is our most powerful plunge cut saw, providing enough power to slice through the toughest of materials with little concern for swirl or burn marks.

    • Depth Of Cut

      At 2 3/4 inch depth of cut, the TS 75 can power through thick stock with ease.

    • Slip Clutch

      A perfect cut the first time, every time, with laser-straight, splinter-free cuts.

    • Guide rail precision

      The TS 75 makes the actual cut right on the edge of the scribe line, even on bevel cuts.


    •



    •



    •



    •



    •



    •



    •



    •



    •



    •



    Technical Data


    Specifications
    Idle engine speed
    1 350 - 4 400 RPM
    Cable length
    4.00 m
    Min. dust extraction connection dia.
    1.06 in
    Saw blade diameter
    8-1/4” (210 mm)
    Drive type
    Mains
    Cutting depth at 45°
    2-1/8” (55 mm)
    Dust extraction connection dia.
    1-1/16"/1-7/16" (27/36 mm)
    Power consumption
    1 600 watt
    Cutting depth
    0" - 3” (0 - 75 mm)
    Angular range
    0 - 47 °
